🔧 Lenovo ThinkPad USB 3.0 Basic Dock 🔧

🖥️ ThinkPad USB 3.0 Basic Dock | Multimedia Expansion | DL3700-ESS | Black

⚙️ PRODUCT CHARACTERISTICS

The Lenovo ThinkPad Basic USB 3.0 Dock is a compact docking station that transforms your laptop into a convenient workstation with a single USB 3.0 cable. The device provides quick connections for peripherals, network, and monitor, eliminating the need to constantly plug and unplug cables. Ideal for office and home use - it saves time, organizes your workspace, and significantly boosts productivity.

📋 TECHNICAL DATA

Model: ThinkPad Basic USB 3.0 Dock (DL3700-ESS)
Front ports: 2× USB 3.0 (1× Always-On for charging devices), 1× combo audio
Rear ports: 2× USB 2.0, 1× DVI-D, 1× RJ-45 Gigabit Ethernet
Video resolution: up to 2048×1152@60 Hz (DVI), up to 1920×1080@60 Hz (VGA)
Dimensions: approx. 135 × 48 × 91 mm
Weight: approx. 309 g
Power supply: external 40 W power adapter (included)

🌟 KEY ADVANTAGES

🔹 One connection for everything – connect monitor, network, and USB devices through a single cable
🔹 Stable HD video – DVI output with included DVI-VGA adapter for greater versatility
🔹 Always-On USB port – ability to charge mobile devices even when the laptop is off
🔹 Gigabit Ethernet – fast and stable network connection for demanding applications
🔹 Compact design – saves desk space and features a convenient power button on the casing
🔹 Universal compatibility – DisplayLink technology ensuring support for many laptop models

🔢 CATALOG NUMBERS

FRU: 03X6285
Equivalent numbers: 03X6777, SD20H13052
Commercial model: 4X10A066WW / 4X10A0668x

❓ WHEN TO REPLACE THE DOCKING STATION?

• Insufficient number of ports – when the laptop has a limited number of USB ports or lacks video output
• Organization issues – when cables on the desk create clutter and hinder work
• Need for a constant monitor connection – when you regularly use an external display
• Lack of Ethernet port – when you need a stable wired connection in an ultrabook

🔧 INSTALLATION PROCESS

Installing the docking station is extremely simple. Connect the power adapter to the dock, then connect the dock to the laptop using the included USB 3.0 cable. Install the DisplayLink/Lenovo drivers (it is recommended to download the latest version from the manufacturer's website). Connect the monitor via the DVI port or VGA adapter and other peripheral devices. The dock is ready to use once the laptop is powered on.

🎯 PURPOSE

The Lenovo ThinkPad USB 3.0 Basic Dock is ideal for users of ThinkPad laptops from the T, L, X series and selected Yoga/Edge/E-series models equipped with a USB 3.0 port. It works perfectly in the office and remote work, where quick setup of a full workstation with a monitor, keyboard, mouse, and stable network connection is needed.

✅ COMPATIBILITY WARRANTY

The offered part has been thoroughly checked and matched to ThinkPad models from the T, L, X series and selected workstations.We guarantee full compatibility with ThinkPad laptops equipped with a USB 3.0 port in the FRU number range 03X6285.The exact appearance and condition of the offered item are shown in the photos in the listing.We provide a 12-month warranty and a 14-day return policy.

📞 NEED HELP? CONTACT OUR EXPERTS!

Do you have questions about the compatibility of the docking station with your laptop? Our specialists are happy to help you choose the right solution. Contact us for professional advice and technical support.
📱 Phone: +48-601-415357
📧 Email: sklep@abcdeal.pl

🦁 ABCDEAL - Your Trusted Lenovo Parts Specialist

For years, we have specialized in providing high-quality parts and accessories for Lenovo laptops. Our experience allows us to offer products that meet the highest standards of quality and reliability. Trust the experts who understand the needs of ThinkPad users and provide solutions tailored to their requirements.

🎯 Choose professionals – invest in high quality!

By choosing the Lenovo ThinkPad USB 3.0 Basic Dock, you are investing in a proven solution that will increase your productivity and comfort at work. Our offer guarantees reliability, technical support, and a long life for your laptop!
