🔧 LCD eDP Display Cable for Lenovo ThinkPad P15 Gen 1 (FHD IPS) 🔧

🖥️ Lenovo ThinkPad P15 Gen 1 | LCD eDP Display Cable | 30-pin FHD | DC02C00L820

⚙️ PRODUCT DESCRIPTION

Brand new, original LCD eDP display cable for Lenovo ThinkPad P15 Gen 1 laptops equipped with a Full HD IPS screen. The cable transmits the video signal between the motherboard and the display panel. It ensures stable image transmission at full Full HD resolution (1920×1080). The part with FRU number 5C10Z23869 guarantees full compatibility with the specified ThinkPad model with an FHD IPS panel.

📋 TECHNICAL SPECIFICATIONS

Type: LCD eDP Display Cable
Brand: Lenovo
Compatibility: ThinkPad P15 Gen 1 (FHD IPS)
Cable model: DC02C00L820
Connector: 30-pin eDP
Resolution: Full HD (1920×1080)
Panel type: IPS
Condition: New

🔑 KEY ADVANTAGES

🔹 Original OEM part — guaranteed perfect fit and full compatibility
🔹 Dedicated FHD IPS cable — supports full Full HD resolution (1920×1080)
🔹 30-pin eDP connector — stable signal transmission to the display panel
🔹 Brand new — guaranteed reliability and long service life
🔹 Direct plug-and-play replacement — no modifications or soldering required

🔢 PART NUMBERS

FRU: 5C10Z23869
Alternatives: DC02C00L820

❓ WHEN TO REPLACE THE LCD eDP CABLE?

• No image on screen — display remains black despite the laptop being powered on
• Screen flickering — unstable image, intermittent flickering during use
• Horizontal or vertical lines — lines or artifacts appearing on the display
• Partial image loss — parts of the screen are dark or distorted
• Mechanical cable damage — bends, cracks, or broken wiring

🔧 INSTALLATION GUIDE

1. Shut down the laptop and disconnect the power adapter.
2. Remove the battery or disconnect its cable from the motherboard.
3. Remove the display bezel — start from a bottom corner, gently pry with a plastic spudger and work around the entire frame.
4. Unscrew the bolts securing the LCD panel to the lid (typically 4 screws in the corners).
5. Carefully tilt the panel forward and rest it face-down on the keyboard.
6. Disconnect the old eDP cable from the panel connector — lift the locking tab and pull out the cable.
7. Peel off the adhesive tape securing the cable along the chassis and disconnect the other end from the motherboard connector.
8. Connect the new cable to the motherboard connector and secure it with adhesive tape.
9. Connect the other end to the panel connector and close the locking tab.
10. Reassemble the laptop in reverse order, tighten the screws and snap the bezel back into place.
11. Power on the laptop and verify the display image is correct.

Replacement is recommended to be performed by a qualified technician or a person experienced in laptop repairs. Use plastic prying tools to avoid scratching the chassis or damaging the delicate connectors.

🎯 APPLICATION

LCD eDP display cable dedicated to Lenovo ThinkPad P15 Gen 1 laptops with an FHD IPS screen. Original part numbers guarantee a perfect fit for this model and screen variant. Restores correct video signal transmission, eliminates flickering and display artifacts, and ensures stable Full HD image quality. Note: FHD and UHD variants require different cables — verify your panel type before ordering.

✅ COMPATIBILITY GUARANTEE

The offered part has been carefully verified and selected for the Lenovo ThinkPad P15 Gen 1 with FHD IPS panel. We guarantee full compatibility with FRU number 5C10Z23869. The exact appearance and condition of the item are shown in the listing photos. In case of any compatibility issues, we offer a hassle-free return within 14 days.
