🔧 SD Audio Cable for Lenovo ThinkPad T480s 🔧

🖥️ ThinkPad T480s | SD/Audio FFC Cable | 01LX984

FFC cable supporting the SD card reader and audio module dedicated to the Lenovo ThinkPad T480s laptop. Part sourced from a working device and tested - we guarantee 100% functionality. FRU number 01LX984 guarantees full compatibility with the ThinkPad T480s model.

⚙️ PRODUCT CHARACTERISTICS

FFC (Flexible Flat Cable) connecting the motherboard to the SD card reader module and audio circuitry in the ThinkPad T480s. Markings on the cable: ET481_SD_FFC, NBX0001LD10 0A, LJYI 18/01/20. The LJYI variant is an equivalent to the MGE variant (FRU 01LX983), both fully compatible with the same model.

📋 TECHNICAL SPECIFICATIONS

Part name: SD Audio cable (FFC)
Brand: Lenovo ThinkPad
Compatible model: ThinkPad T480s
Condition: Used (removed from a working unit, tested)
FRU: 01LX984
Equivalent part numbers: 01LX983
Markings on part: ET481_SD_FFC, NBX0001LD10 0A, LJYI 18/01/20

🌟 KEY ADVANTAGES

🔹 Genuine Lenovo part - guaranteed perfect fit and reliability
🔹 Tested functionality - cable tested before listing, SD reader and audio work correctly
🔹 Full compatibility - matched to the ThinkPad T480s under FRU 01LX984 (equivalent 01LX983)
🔹 Quick replacement - ready for direct installation, no modification needed

🔢 PART NUMBERS

FRU: 01LX984
Equivalent part numbers: 01LX983
Laptop model: Lenovo ThinkPad T480s

❓ WHEN SHOULD YOU REPLACE THE SD AUDIO CABLE?

• The SD card reader does not detect an inserted memory card
• Speaker or microphone sound stopped working or cuts out when the chassis is flexed
• The SD card is detected intermittently, even though the card itself works in another device
• Visible crack or fraying on the cable during disassembly

🔧 INSTALLATION PROCESS

1. Turn off the laptop and disconnect power along with all external devices
2. Remove the screws securing the bottom cover and carefully take it off
3. Disconnect the battery from the motherboard
4. Disconnect the old cable from the motherboard connector and the SD/audio module
5. Connect the new cable, making sure it seats correctly in both connectors
6. Reinstall the battery and bottom cover, power on the laptop and verify the SD reader and audio work
Replacement recommended by a technical service or a person experienced in laptop repairs.

🎯 PURPOSE

This cable is intended for repairing a ThinkPad T480s with a non-working SD card reader or audio issues. A solution for those wanting to restore full laptop functionality without replacing the entire motherboard.

✅ COMPATIBILITY GUARANTEE

The offered cable has been thoroughly checked and matched to the Lenovo ThinkPad T480s model. We guarantee full compatibility under FRU 01LX984 and 100% functionality of the part. In case of any compatibility issues, we provide a hassle-free 14-day return.

📞 NEED HELP? CONTACT OUR EXPERTS!

Do you have questions about the compatibility of this cable with your ThinkPad T480s? Our specialists will be happy to assist you. Contact us!
📱 Phone: +48-601-415357
📧 Email: sklep@abcdeal.pl

🦁 ABCDEAL - Your Trusted Lenovo Parts Specialist

We have been specialising in delivering genuine Lenovo laptop parts for years. Our experience allows us to offer top-quality products that meet the expectations of even the most demanding customers. Trust the experts and restore your ThinkPad T480s to full functionality.

🎯 Choose professionals - invest in quality!

By choosing a tested SD Audio cable for the Lenovo ThinkPad T480s from our offer, you invest in reliability and full functionality of the card reader and audio. Take advantage of ABCDEAL's expertise and restore your laptop to full working order.
