🔧 Lenovo 170W 20V 8.5A Slim Tip AC Adapter for ThinkPad P and Legion 🔧

🖥️ ThinkPad P50 P51 P52 P53 P15 P17 W540 | 170W slim tip AC adapter | 45N0560

Genuine Lenovo 170W (20V, 8.5A) AC adapter with a rectangular slim tip, model ADL170NLC2A manufactured by Lite-On. Used adapter, tested and 100% functional. Full power for ThinkPad P and W mobile workstations and Legion, LOQ and IdeaPad Gaming laptops, with spare power for any Lenovo with a rectangular jack that originally came with a weaker adapter.

⚙️ PRODUCT CHARACTERISTICS

170W AC/DC power adapter with 20V output at 8.5A and a yellow rectangular slim tip. The laptop draws only the power it needs, so a 170W adapter can safely be used with a model that originally came with 135W, 90W or 65W. It works on 100-240V 50/60Hz mains. The label carries MODEL ADL170NLC2A, PA-1171-71, LC PN 36200321, LI PN 45N0375, FRU PN 45N0560. Supplied with a power cord with a two-pin European plug.

📋 TECHNICAL DATA

Part name: 170W AC/DC power adapter
Brand: Lenovo
Adapter model: ADL170NLC2A / PA-1171-71 (Lite-On)
Power: 170W
Output: 20V, 8.5A
Input: 100-240V, 2.5A, 50-60Hz
Connector: rectangular slim tip (yellow)
Power cord socket: two-pin (2-pin)
Package contents: adapter + power cord with European plug
Condition: Used, tested, 100% functional
Warranty: 6 months
FRU: 45N0560
Cross reference numbers: 45N0375, 36200321, 45N0487, 45N0376, 45N0372, 02DL137, 02DL139, 02DL141
Equivalents with three-pin cord (3-pin): 02DL140, 02DL136, 02DL138, 45N0370, 45N0374, 45N0514, 45N0558, 01FR043, 5A10J46694, 5A10J75115, 5A11K67849, 5A11K67850, 5A11K67851, 5A11Q60430, 5A11Q60433, 5A11Q60436, 5A11Q60444, 36200316, 36200320
Label markings: MODEL ADL170NLC2A, PA-1171-71, LC PN 36200321, LI PN 45N0375, FRU PN 45N0560, Rev.600, Lite-On

💻 COMPATIBLE MODELS

ThinkPads shipped with a 170W adapter (full power):
• W540, W541, P50, P51, P52, P53, P70, P71, P73
• P15 Gen 1, P15 Gen 2, P17 Gen 1, P17 Gen 2, P16 Gen 1, P16 Gen 2, P16v Gen 1, P16v Gen 2, T15g Gen 1, T15g Gen 2
• P1 Gen 3, P1 Gen 4, P1 Gen 5, P1 Gen 6, P1 Gen 7, X1 Extreme Gen 3, X1 Extreme Gen 4, X1 Extreme Gen 5

ThinkPads shipped with a 135W or weaker adapter (170W gives spare power):
• P1, P1 Gen 2, X1 Extreme, X1 Extreme Gen 2, P15v Gen 1, P15v Gen 2, P15v Gen 3, T15p Gen 1, T15p Gen 2
• T440p, T540p, T460p, T470p and other ThinkPads with a rectangular slim tip jack (T440-T570, L440-L570, E431-E575, X240-X270)

Lenovo Legion, LOQ, IdeaPad Gaming, IdeaPad Pro and Yoga Pro:
• Legion 5-15ARH05, 5-15IMH05, 5-17IMH05, 5P-15IMH05, Legion 5 15AHP10, 15IRX10, Legion S7-15ACH6, S7-15ARH5, S7-15IMH5, S7 16ARHA7, S7 16IAH7
• Legion Slim 5 14APH8, 16APH8, 16IRH8, 16AHP9, 16ARP9, Legion Y530-15ICH, Y540-15IRH, Y540-17IRH, Y545, Y7000, Y7000P, Y720-15IKB
• LOQ 15APH8, 15IRH8, 16APH8, 16IRH8, 15AHP9, 15ARP9, 15IAX9, 15IRX9, 15AHP10, 15IRX10
• IdeaPad Gaming 3 15ACH6, 15IHU6, 15ARH7, 15IAH7, 16ARH7, 16IAH7
• IdeaPad Pro 5 16APH8, 16IRH8, 16AHP9, 16IMH9, 16IAH10, 16AKP10, 16IPH11, Yoga Pro 9 16IRP8, 16IMH9, 16IAH10, 16IPH11, Slim Pro 9 16IRP8

Docking stations: ThinkPad Ultra Dock, ThinkPad Thunderbolt 3 Dock Gen 2, Lenovo Thunderbolt 3 Graphics Dock

⚠️ Models that in their most powerful configurations ship with a 230W adapter (e.g. P72, P53, P15, P17, T15g, Legion with RTX 2070/3070 graphics and above) run on 170W, but under full load the graphics card may run at reduced power and the battery charges more slowly.

List based on Lenovo Parts Lookup (FRU 45N0560 and substitutes) and the PSREF specifications of each model.

🌟 KEY ADVANTAGES

🔹 Genuine Lenovo adapter - the laptop correctly detects 170W, with no insufficient adapter warnings on models specified for 170W
🔹 Full power for graphics - P50, P52 or Legion 5 run with full graphics performance while charging the battery, with no throttling during rendering or gaming
🔹 Spare power for weaker models - the same slim tip fits T440p, T540p or P1, so one powerful adapter serves every ThinkPad in a mixed office
🔹 Wide 100-240V input range - works in Poland and abroad
🔹 Tested before shipping - used adapter, tested, with a 6-month warranty

🔢 PART NUMBERS

FRU: 45N0560
Cross reference numbers: 45N0375, 36200321, 45N0487, 45N0376, 45N0372, 02DL137, 02DL139, 02DL141
Equivalents with three-pin cord (3-pin): 02DL140, 02DL136, 02DL138, 45N0370, 45N0374, 45N0514, 45N0558, 01FR043, 5A10J46694, 5A10J75115, 5A11K67849, 5A11K67850, 5A11K67851, 5A11Q60430, 5A11Q60433, 5A11Q60436, 5A11Q60444, 36200316, 36200320
Label markings: MODEL ADL170NLC2A, PA-1171-71, LC PN 36200321, LI PN 45N0375, FRU PN 45N0560, Rev.600, Lite-On

❓ WHEN SHOULD YOU REPLACE THE AC ADAPTER?

• Problem with battery charging - the adapter is plugged in, but the charge level stays the same or drops while working
• Problem with an insufficient wattage warning after connecting a weaker 90W or 135W charger
• Problem with performance - the laptop slows down in games and graphics software because the adapter does not deliver full power
• Problem with a damaged cable or tip - frayed insulation, loose fit in the jack
• Problem with a missing adapter - lost, left at work, or a second one needed for home

🔧 CONNECTION

1. Connect the power cord to the socket on the adapter
2. Plug the cord into a 100-240V mains outlet
3. Connect the rectangular slim tip to the laptop power jack (the tip fits either way up)
4. Check that the charging LED lights up and the system shows the battery charging
No drivers or configuration are required.

🎯 PURPOSE

An adapter to replace a worn or lost charger for a mobile workstation or gaming laptop, as a second one for home or office, or a more powerful replacement for laptops with a 135W or weaker adapter. It fits Lenovo laptops with a rectangular power jack. The exact appearance and condition of the offered item are shown in the photos.

✅ COMPATIBILITY GUARANTEE

The offered adapter has been tested and matched by FRU 45N0560 and its substitutes from the Lenovo database. We guarantee full compatibility with the listed models and 100% functionality. The adapter comes with a 6-month warranty, and if there is any compatibility issue we offer a hassle-free return within 14 days.
